Commercial Roofing Projects That We Have Completed

Greenshaw High School

Value £361,000

Description: Replacement of failed flat roof system with new high performance felt and cut to falls insulation.

Scaffold erection prior to commencement
Works in progress
Part completed works
Works nearing completion

Kingston Hospital

Value £350,000

Description: Preparation of failed asphalt, installation of Garland liquid waterproofing and cementitious topped insulation to provide level roof terrace. To preserve patient dignity scaffolding was not permitted and the roof had to be serviced from a mobile crane once a week. Other inaccessible areas were completed by specialist abseiling teams.

Prior to commencement
Debris on roof
Removing debris via crane
Seven storey crane lift
New ductwork support
Perimeter ballast detail
Bespoke cable duct
New AC plant supports
Roof cleaned off prior to commencement
Screed vent detail
Completed works
AC banks relocated

NHS Supply Chain

Value £150,000

Description: Replacement of defective roof lights with new reinforced GRP factory assembled triple skin roof lights.

Heavily degraded existing GRP rooflight
Replacement rooflight with red fixings
Overview of rooflight replacement

Guildhall 1

Value £195,000

Description: Flat Roof Area 480 M2 Mansard Area 790 M2 Product ICB – Alwitra Evalon V – Single Ply Membrane

The site set-up was extremely complicated as the building is part of the Guildhall Complex and as such, was occupied throughout the works. The ground level perimeter being a public thoroughfare on three sides, added to the challenges. Security was paramount and the neighbouring buildings included the magistrates court.

The initial works consisted of a relatively simple overlay of the flat roof areas incorporating an upgrade of the insulation. The mansard areas were a completely different challenge and involved removing the lead and chipboard bonded panels, many of which had become soft with the years of water ingress. Insulation was placed in the voids and covered with 18mm OSB 3 to provide a sound base for the Evalon V to be fully adhered to. Much of the Eva-Metal detailing, and especially around the existing windows was designed on-site by the team and fabricated in Bournemouth by ICB.

The product was chosen for its colour resemblance to lead and once the mansard areas were broken up with vertical standing seam profiles, the finished work was very similar to how the building would have looked when new.

Click here to read more on ICB’s website

New single ply dormer application
Installation designed to replicate original lead cladding

Christies Auctioneers

Value £244,000

Description:
Roof Area 3,600m²
Overlay existing standing seam aluminium roof with insulated, fully bonded single ply system.

Existing aluminium standing seam roof
New single ply overlay
Parapet details
Installation included new perimeter handrails for safe future access

Adams and Adams

Value £421,419 (over 4 phases)

Description:
Roof Area 3960m²
Cladding Area 860m²
This site was constructed prior to World War 2 and parts of the site were used to produce the fuselage for the Hawker Hurricane fighter plane. The site now has a thoroughly modern appearance of a recently developed site.

Prior to commencement
Historic photos supplied by the client
Historic photos supplied by the client
Historic photos supplied by the client
Historic photos supplied by the client
Overview of six completed roof areas
Low level units roofing and cladding
Roller shutter and gutter in contrasting colour
Bespoke gutter and off-set rainwater pipe
Roller shutter doors
Wall cladding with contrasting verge flashings
Replacement roof covering with new rooflights

Chertsey Ambulance

Value £39,969.00

Description:
Roof Area 540m²
Removal of existing asbestos cement roof covering and installation of new Kingspan composite roof.

Existing asbestos cement roof
Existing asbestos cement roof
Existing internal view
New composite panel roof and insulated rooflights
Composite panel and felted gutter detail
New composite panel roof and insulated rooflights
Completed roof with increased levels of natural daylight
Factory assembled insulated rooflights

DHL

Value £635,567

Description:
Roof Area 8,385m²
Removal of existing Asbestos Cement roof and installation of Kingspan Composite Roof panels in conjunction with Rooflights supplied by Brett Martin Daylight Systems and Ampteam Unifold gutter lining.

Existing asbestos cement roof
New composite panel roof and insulated rooflights
Existing asbestos cement roof
Existing asbestos cement roof
New composite panel roof and insulated rooflights
New composite panel roof and insulated rooflights

Cavendish Court

Value £171,233.00

Description:
Roof Area 620 m²
Client – Housing 21
Removal of existing interlocking concrete roof tiles and installation of new Garland high performance insulated built up felt roof.

Full scaffold and temporary roof
Existing moss covered concrete tiles
Completed high performance felt installation

Thistley Hill

Value £100,823.00

Description:
Roof Area 770m²
Client – Kent County Council
Removal of failed flat roof system and installation of new Garland High Performance insulated flat roof system.

Existing failed flat roof
Existing failed flat roof
Existing failed flat roof
Completed high performance felt roof covering
Completed high performance felt roof covering
Completed high performance felt roof covering
Unconventional outlet detail
Revised outlet detail

Kuoni Travel Limited

Value £127,290

Description:
Roof Area 1300m²
Removal of failed flat roof system and installation of new Garland High Performance insulated flat roof system.

Completed roof felt and glass over staircase
Completed lower level felt roof
Kuoni HQ

Kelvin House

Value £62,181.00

Description:
Roof Area 450 m²
Repair of existing asphalt roof covering followed by an application of Garland Whiteknight liquid waterproofing system, with a 20 year warranty.

Existing failed roof
New liquid waterproofing application to glazing detail
Overview of new liquid treated roof

Thames Street. Staines

Description:
Roof Area 800m²
Repair of existing asphalt roof covering followed by an application of Garland Whiteknight liquid waterproofing system, with a 20 year warranty.

New roof access hatch and designated walkway demarcation
Overview of new liquid treated roof
Overview of new liquid treated roof
